Hydraulic magnet HMT 100
HMT Magnet Generators and Hydraulic Magnets convert the hydraulic power of mobile machinery into electricity for powering lifting magnets and hydraulic magnets. Hydraulically operated magnet HMT 100 for collecting scrap and metal in demolition, recycling, railroad and road side cleaning.
HMT 100 is equipped with teeth which enable material moving. It can be easily and rapidly mounted on any kind of excavator by quick hitch adapter.
Hydraulic magnet applications
- Powering lifting magnets
- Plug-and-play magnets with integrated magnet generator
- Scrap and metal collecting in construction, demolition and recycling
- Railway and road side cleaning
- Metal separation
- Transport and collection of scrap
- Teeth installed to bottom for material moving
Hydraulic magnet features
- High quality structure
- Easy to connect hydraulic magnet without installation
- No electric cables
- Standard delivery includes two hydraulic hoses and lifting chains
- Additional quick attachments are available on request
- Generator is fully enclosed in the hydraulic magnet's steel cover
- Diameter 1000 mm
- for 12-18 t excavators
- lifting ability 5 t
- Oil flow 150 l/min
- Pressure 200 bar
- Power 8 kW
- Weight 1350 kg
Boost your productivity: introducing the Blue HMT hydraulic magnet – the ultimate scrap and metal handler
Are you looking to dramatically increase efficiency in your demolition, recycling, or site-cleaning operations? Stop wasting time and labor on manual metal collection. Meet the Hydraulic magnet blue HMT from Green Attachments – a powerful, hydraulically-operated attachment engineered to transform how you handle ferrous materials.
The HMT is not just a magnet; it's a complete material handling solution designed for the demanding environments of the construction and recycling industries.
Why the HMT is a game-changer
The HMT excels where traditional magnets fall short, offering a seamless and robust integration with your existing mobile machinery.
Key Features and Performance Benefits:
|
Feature
|
Specification / Detail
|
Benefit to Your Operation
|
|
Model
|
HMT
|
Easy reference and part identification.
|
|
Operation
|
Fully hydraulically operated
|
No external generator or complex electrical wiring needed. Plug-and-play simplicity!
|
|
Integrated Power
|
Converts hydraulic power into electricity via an enclosed generator.
|
Reliability and protection—the generator is fully enclosed in the magnet's steel cover, safeguarding it from harsh conditions.
|
|
Diameter
|
960-1500 mm
|
A substantial surface area for maximum lifting and collecting capacity.
|
|
Innovative Design
|
Equipped with Teeth on the bottom.
|
Unique capability for material moving in addition to lifting, allowing you to easily sweep and gather scrap.
|
|
Quick Installation
|
Easily and rapidly mounted on any kind of excavator by quick hitch adapter.
|
Minimal downtime; maximize utilization across your fleet.
|
|
Power & Efficiency
|
Power: 8 kW, Oil Flow: 150 l/min, Pressure: 200 bar.
|
High magnetic power ensures a secure and efficient lift, optimizing cycle times.
|
|
Standard Inclusions
|
Includes two hydraulic hoses
|
Ready to deploy right out of the box (quick attachments available upon request).
|
Applications: where the HMT shines
The versatility of the HMT makes it an indispensable tool across multiple sectors:
- Demolition: Rapidly and effectively separate steel and metal debris from concrete and rubble, significantly improving sorting efficiency on-site.
- Recycling and Scrap Yards: Essential for transporting, sorting, and collecting various types of scrap metal.
- Infrastructure Cleaning: Ideal for railway and road side cleaning, ensuring metal hazards are cleared quickly and safely.
- Construction Sites: Effortlessly clear construction sites of stray metal, nails, and other ferrous foreign objects to enhance safety and prevent machinery damage.
Technical specifications at a glance
For professionals who demand the numbers, the Blue HMT delivers:
- Reference: HMT 100
- Diameter: 1000 mm
- Oil Flow Requirement: 150 l/min
- Pressure Requirement: 200 bar
- Power: 8 kW
- Weight: 1350 kg
Maximize your roi with a seamless solution
Investing in the Hydraulic Magnet HMT is an investment in unparalleled operational efficiency:
- Reduce downtime: Its robust, high-quality structure and easy, cable-free hydraulic connection mean fewer maintenance headaches and more time working.
- Increase productivity: The combination of a powerful magnet and material-moving teeth allows a single machine to perform both collection and sorting tasks simultaneously.
- Enhance safety: Clean up dangerous metallic debris quickly, making your work environment safer for personnel and machinery (especially tires!).
Upgrade your equipment with the magnetic power of the HMT. For purchasing inquiries, availability, or to request a quote, contact Green Attachments today!
Technical specs of HMT100
| Weight |
kg |
1350 |
| Excavator |
t |
12 - 18 |
| Lifting ability |
t |
3 - 5 |
| Pressure |
bar |
200 |
| Oil flow |
l / min |
100 - 150 |
| Power |
kW |
8 |
| Diameter |
mm |
1000 |
| Teeth |
pcs |
3 |
