Cutter Crusher Yellow C 5000 (50 … 65 t) 4800 kg
Green Attachments cutter crusher Yellow C range has been created for the most demanding and precise primary demolition applications. Yellow C cutter crushers are suitable for the demolition of reinforced concrete structures and the high rise building demolition, mounted on long reach demolition booms. The product has a robust structure and powerful and efficient productivity. The geometry makes sure that maximum power is reached just in the right moment and two cylinder kinematics allows very high power also in the end of the movement when high cutting force is needed.
Robust structure of cutter crushers with fast and powerful performance allows efficient demolition, the most typical are reinforced concrete structures. There are cutting blades in order to cut reinforcements. Yellow RS cutter crusher design has been made according to customer’s needs to acquire light and durable structure combined with high power and efficienfy.
Cutter crusher are designed with flange which allows the customer to change adapter easily. Green Attachments provides different adapters when needed.
The Yellow C cutter crusher range consists of twelve models for 1.5 - 130 tonne excavators (3 300 – 290 000 lb)
Cutter Crusher applications
- Demolition, industrial buildings, houses
- Special demolition,factories, bridges...
- Long reach applications
- Steel cutting
Features of Yellow C cutter crushers
- Wear resistant steel has been used to decrease wearing. It is essential to build all parts which touch the material by wear resistant material.
- Yellow C cutter crushers have a high speed valve to increase performance. Then oil is rotated from rod side to piston side regeneratively, all products has not that feature.
- Cutter crusher teeth are made of special forged material. They are easily replaceable
- Wear resistant cutting blades are bolt mounted and easily reversible.
- Axels are hardened and greasing points has been designed to make maintenance easy.
- Cutter crushers have changeable steel bushings and they have been over sized in order to increase life time.
- Slew bearing has double roll desing (bigger models) to increase strength.
- Hydraulic rotation makes positioning of cutter crushes easy. Durable orbital hydraulic motors have a gear in order to maximise power and productivity.
- Hydralic motors are equipped with double pressure relief valves
- Cutter crushers have easily removeable maintenance covers to decrease service time
- Big cylinders ensure huge power and they are reversed in order to protect cylinder rod.
- Cutter crushers have well designed hydraulics to minimize overheating.
Specs of Yellow C cutter crushers
| Weight |
|
kg / lb |
4800 / 10600 |
| Excavator weight |
|
t /1000 lb |
50 - 65 / 110 - 144 |
| Opening |
|
mm / Inch |
1500 / 59.1 |
| Height |
|
mm / Inch |
2850 / 112.2 |
| Blade length |
|
mm / Inch |
320 / 12.6 |
| Cutting force |
|
t /1000 lb |
480 / 1056 |
| Crushing force (tip) |
|
t /1000 lb |
140 / 308 |
| Working pressure |
|
bar / psi |
340 / 4960 |
| Excavator oil flow |
|
l/min / gpm |
400 / 107 |
| Rotation pressure max |
|
bar / psi |
100 / 1460 |
| Rotation oil flow max |
|
l/min / gpm |
60 / 16 |
